TRAIN CONTROL SYSTEMS DIGITAL DECODERS

The TCS One-Year Goof-Proof No-Questions-Asked Warranty We will repair/replace the decoder even if you accidentally damage it. All TCS decoders are covered. Defective decoders can be sent directly to TCS. Decoders will be repaired or replaced at TCS' discretion.



THIS IS THE REASON HOGTRAINZ RECOMMENDS TCS DECODERS

HIGH QUALITY - GOOF PROOF WARRANTY

FULL INSTALLATION INSTRUCTION WITH PICTURES ON THEIR WEBSITE

http://www.tcsdcc.com/Customer_Content/Products/Decoders/HO-Scale/HO%20Series.htm

NOW IS THE TIME TO GET WITH THE PROGRAM - GO DIGITAL!!!!!
Description
Item Number		 Price Qty to
Order		 Add
Item
Four-function (headlight/reverse light and two extra functions), 1.3-amp continuous 2.0 amp peak, HO "drop in" decoder for Atlas, Athearn, Kato, Bachmann, etc. The A4X features TCS exclusive, auto-adjusting BEMF. Dimensions: 2.860”x0.680”x0.145” or 72.64mm x 17.272mm x 3.683mm
A4X 4 FUNCTION 1.3 AMP DECODER
TCS-1000

$22.95
LIST: $27.95
Six-function (headlight/reverse light and four extra functions), 1.3-amp continuous 2.0 amp peak, 1.3-amp HO "drop in" decoder with on board 1.5 volt regulated power supply for Atlas, Athearn, Kato, Bachmann, etc. The A6X features TCS exclusive, auto-adjusting BEMF, and an onboard 1.5v supply. Dimensions: 2.860”x0.680”x0.145” or 72.64mm x 17.272mm x 3.683mm
A6X 6FUNCTION 1.3 AMP DECODER
TCS-1001

$26.95
LIST: $32.95
Six-function (headlight/reverse light and four extra functions), 1.3-amp continuous 2.0 amp peak, 1.3-amp HO "drop in" decoder with on board 1.5 volt regulated power supply for Atlas, Athearn, Kato, Bachmann, etc. The A6X features TCS exclusive, auto-adjusting BEMF, and an onboard 1.5v supply. Dimensions: 2.860”x0.680”x0.145” or 72.64mm x 17.272mm x 3.683mm
FL2 2 FUNCTION LIGHTING DECODER
TCS-1002

$17.25
LIST: $19.25
FL2 2 FUNCTION LIGHTING DECODER - 5 PACK
TCS-1003

$74.25
LIST: $87.10
The M1 is a micro, hardwire HO & N scale decoder. This decoder can be hardwired, or purchased with a few 8 pin NMRA harnesses attached. Provides 1 amp continuous and 2 amp peak draw. The M1 features the TCS exclusive auto-adjusting BEMF. The M1 is a motor control decoder with two lighting functions (headlight and reverse light) Dimensions .567”x.359”x.135” or 14.4mm x 9.12mm x 3.43mm
M1 2 FUNCTION MICRO DECODER
TCS-1006

$25.50
LIST: $31.45
M1P 2 FUNCTION MICRO DECODER WITH HARNESS
TCS-1007

$29.50
LIST: $36.45
M1P-15 DECODER FOR ATLAS MP-15
TCS-1008

$29.50
LIST: $36.45
The M3 is a micro, hardwire HO & N scale decoder. This decoder can be hardwired, or purchased with a few 8 pin NMRA harnesses attached. Provides 1 amp continuous and 2 amp peak draw. The M3 features the TCS exclusive auto-adjusting BEMF. The M3 is a motor control decoder with three lighting functions (forward/reverse light, and one extra function) Dimensions .567”x.359”x.135” or 14.4mm x 9.12mm x 3.43mm
M3 - 3 FUNCTION HO OR N SCALE DECODER
TCS-1009

$28.50
LIST: $34.60
The M4 is a micro, hardwire HO & N scale decoder. This decoder can be hardwired, or purchased with a few 8 pin NMRA harnesses attached. Provides 1 amp continuous and 2 amp peak draw. The M4 features the TCS exclusive auto-adjusting BEMF. The M4 is a motor control decoder with four lighting functions (headlight, reverse light, and 2 extra functions) Dimensions .567”x.359”x.135” or 14.4mm x 9.12mm x 3.43mm
M4 - HO 4 FUNCTION DECODER
TCS-1011

$32.50
LIST: $38.80
MC4 - HO 6 FUNCTION 7 PIN DECODER
TCS-1017

$26.50
LIST: $31.95
An HO scale decoder a 9 pin socket. This decoder can be hardwired, plugged straight into some locomotives, or connected to the 8-pin NMRA sockets using a variety of the available harnesses. Provides 1.3 amp continuous and 2 amp peak draw. The T1 features TCS exclusive auto-adjusting BEMF. The T1 is a motor control decoder with two lighting functions (headlight and reverse light) Dimensions .956”x.655”x.207” or 24.28mm x 16.63mm x 5.25mm
T1 - HO 2 FUNCTION 9 PIN DECODER
TCS-1021

$19.25
LIST: $22.00
T1P- MH HO 2 FUNCTION DECODER WITH HARNESS
TCS-1022

$22.25
LIST: $27.00
T1A- HO 2 FUNCTION DECODER
TCS-1023

$18.25
LIST: $20.90
An HO scale decoder a 9 pin socket. This decoder can be hardwired, plugged straight into some locomotives, or connected to the 8-pin NMRA sockets using a variety of the available harnesses. Provides 1.3 amp continuous and 2 amp peak draw. The T6X features TCS exclusive auto-adjusting BEMF. The T6X is a motor control decoder with six lighting functions (headlight, reverse light, and 4 extra functions) Dimensions .956”x.655”x.207” or 24.28mm x 16.63mm x 5.25mm
T6X- HO 6FUNCTION 9 PIN DECODER
TCS-1026

$24.00
LIST: $27.95
An HO scale decoder with a built in 8 pin NMRA plug. By far one of the easiest decoders to install, the DP2X can be plugged into many locomotives with no effort. Provides 1 amp continuous and 2 amp peak draw. The DP2X features TCS exclusive auto-adjusting BEMF. The DP2X is a motor control decoder with two lighting functions (headlight and reverse light) Dimensions: .460”x.690”x.140” or 11.7mm x17.5 mm x 3.5mm
DP2X - HO 1.3 AMP PLUG AND PLAY DECODER
TCS-1028

$20.75
LIST: $24.95
